6406


$997.50

Garage Stalls: 3
Bedrooms: 3
Bathrooms: 2
Pitch: 8/12
Width (ft): 50
Depth (ft): 68
Veneer sqft: 1995
Total Under Roof sqft: 2853
Height (ft): 24

SKU: 6406 Category:

Description

This cozy craftsman features a large living room, sizable covered patio, an over-sized utility room, and a computer area. Also, the kids can have their own study area with desks built into each of their bedrooms. The master bath includes a separate shower and tub with a double vanity and built-in shoe racks in the spacious master closet. The kitchen and dining area are open to each other and both are semi-open to the living room (for those who don’t like to mix dinner and TV). The kitchen features an island with a raised snack bar for bar stools and separate range and oven. Other household conveniences include a mud bench and drip rod in the utility, and drop zones in the entry and garage.

What's Included

  • Site Plan (if needed): A scaled drawing showing the home's placement on the lot, including setbacks, driveway location, basic grading, and utility connections where applicable. (Provided when required by local permitting authorities.)
  • Foundation Plan: Foundation layout showing footing locations, slab or basement configurations, pier placements, and general structural notes. If engineering is required, this can be provided for an extra fee.
  • Floor Plan: Comprehensive layout of each level showing room dimensions, wall placements, door and window sizes, cabinetry, and fixtures. This plan serves as the primary reference for plumbers, HVAC, and other trades during construction.
  • Electrical Layout: Basic electrical plan showing general fixture and outlet placements, switches, and lighting locations.
  • Exterior Elevations: Exterior views of all four sides of the home showing roof pitches, window and door styles, materials, and overall appearance.
  • Roof Layout: Basic roof plan showing pitches, ridges, valleys, overhangs, and drainage layout. (Trusses engineered by truss company.)
  • Digital Plan Files: All plans delivered in high-quality PDF format for easy viewing, printing, and sharing.

*Additional documentation or visualization: Documentation not required for permitting or not included in a particular package is billed at $150/hr (e.g. framing plans, cabinet details, sections, color renderings, 3D visualization, etc.). Call for quote.

*Engineered foundations: Engineered documentation is billed separately by our engineering partners.
