5732


$750.00

Garage Stalls: 2
Bedrooms: 3
Bathrooms: 2
Pitch: 7/12
Width (ft): 45
Depth (ft): 56
Veneer sqft: 1433
Total Under Roof sqft: 1864
Height (ft): 17

SKU: 5732 Category:

Description

Traditional home has a deep entry case opening into dining room. Kitchen has open snack bar, pass through over sink. Utility room has a pantry and door out to car. Living room is very spacious has garden door out to patio not covered and fireplace. Master bedroom has 10′ sloped ceilings and a picture window. Master bath has a shower, tub and walk in closet with doors on each end. Second bedroom has a walk in closet and hall coat closet. Third bedroom has a standard closet, cathedral ceilings and both bedrooms share hall bath.

Large Family & Master Bedroom Hi-Lite This Plan

What's Included

  • Site Plan (if needed): A scaled drawing showing the home's placement on the lot, including setbacks, driveway location, basic grading, and utility connections where applicable. (Provided when required by local permitting authorities.)
  • Foundation Plan: Foundation layout showing footing locations, slab or basement configurations, pier placements, and general structural notes. If engineering is required, this can be provided for an extra fee.
  • Floor Plan: Comprehensive layout of each level showing room dimensions, wall placements, door and window sizes, cabinetry, and fixtures. This plan serves as the primary reference for plumbers, HVAC, and other trades during construction.
  • Electrical Layout: Basic electrical plan showing general fixture and outlet placements, switches, and lighting locations.
  • Exterior Elevations: Exterior views of all four sides of the home showing roof pitches, window and door styles, materials, and overall appearance.
  • Roof Layout: Basic roof plan showing pitches, ridges, valleys, overhangs, and drainage layout. (Trusses engineered by truss company.)
  • Digital Plan Files: All plans delivered in high-quality PDF format for easy viewing, printing, and sharing.

*Additional documentation or visualization: Documentation not required for permitting or not included in a particular package is billed at $150/hr (e.g. framing plans, cabinet details, sections, color renderings, 3D visualization, etc.). Call for quote.

*Engineered foundations: Engineered documentation is billed separately by our engineering partners.
