5238


$780.50

Garage Stalls: 2
Bedrooms: 3
Bathrooms: 2
Pitch: 8/12
Width (ft): 50
Depth (ft): 49
Veneer sqft: 1561
Total Under Roof sqft: 2069
Height (ft): 22

SKU: 5238 Category:

Description

Traditional home has 10′ ceilings as you come in a coat closet and door to utility room. Utility room has doors to entry, garage and kitchen. Kitchen is L shaped has a small pantry and opens to dinette with a box window. Living room has a garden door out to covered patio, a window on each side of fireplace and 10′ ceilings. Master bedroom has 8′-9′ ceilings with two windows. Master bath has a corner garden tub, shower and walk in closet. Two more bedrooms with standard closets and hall bath to share.

What's Included

  • Site Plan (if needed): A scaled drawing showing the home's placement on the lot, including setbacks, driveway location, basic grading, and utility connections where applicable. (Provided when required by local permitting authorities.)
  • Foundation Plan: Foundation layout showing footing locations, slab or basement configurations, pier placements, and general structural notes. If engineering is required, this can be provided for an extra fee.
  • Floor Plan: Comprehensive layout of each level showing room dimensions, wall placements, door and window sizes, cabinetry, and fixtures. This plan serves as the primary reference for plumbers, HVAC, and other trades during construction.
  • Electrical Layout: Basic electrical plan showing general fixture and outlet placements, switches, and lighting locations.
  • Exterior Elevations: Exterior views of all four sides of the home showing roof pitches, window and door styles, materials, and overall appearance.
  • Roof Layout: Basic roof plan showing pitches, ridges, valleys, overhangs, and drainage layout. (Trusses engineered by truss company.)
  • Digital Plan Files: All plans delivered in high-quality PDF format for easy viewing, printing, and sharing.

*Additional documentation or visualization: Documentation not required for permitting or not included in a particular package is billed at $150/hr (e.g. framing plans, cabinet details, sections, color renderings, 3D visualization, etc.). Call for quote.

*Engineered foundations: Engineered documentation is billed separately by our engineering partners.
